Catch Basin Replacement: A Behind-the-Scenes Look at Pavemar Paving in Action

When a storm drain starts to sink or crack, it can quickly become a big problem in any parking lot.
At Pavemar Paving, we were recently called out to a residential building in Toronto to fix just that - a broken catch basin surrounded by cracked asphalt.

Here's a step-by-step look at how our team handled it from start to finish.

Step 1: Safety First and Marking the Area
We started by blocking off the area around the damaged storm drain with cones and bright paint.
This helps keep everyone safe while letting us mark where we’ll be cutting and digging.

Step 2: Opening Up the Ground
Next, our crew carefully removed the metal drain cover and inspected the inside.
We noticed the base was crumbling and not properly connected to the drainage pipe anymore.

Step 3: Digging and Removal
Using our backhoe, we dug out the broken concrete catch basin and the surrounding gravel and soil.
This gives us a clean and sturdy spot for the new Pre-Cast Concrete structure.

Step 4: Placing the New Catch Basin
Once the hole was ready, we lowered in a brand-new precast concrete catch basin.
Our team made sure it was level and connected perfectly to the existing drainage pipe.

Step 5: Backfilling and Compaction
After installing the new basin, we filled the area back in with layers of gravel.
Each layer was packed down tightly using a compactor to prevent the ground from sinking later on.

Step 6: New Asphalt Surface
The final step was to patch the area with fresh, hot asphalt.
We made sure the surface was smooth and flush with the rest of the parking lot.

Storm Drain Repairs Matter.

Broken or sunken drains don’t just look bad - they can cause water damage, trip hazards, and bigger problems.

Fixing them fast helps protect your property and the people who use it.

Need Catch Basin Repairs in Toronto?
Whether you’re managing a residential building, commercial plaza, or industrial building, Pavemar Paving has over 30 years of experience fixing catch basins and paving surfaces across the GTA.
We get the job done right—the first time.
